BOLT VII PRO Series Laser Cutting Machine
BOLT VII PRO Series Laser Cutting Machine
Penta Laser BOLT VII PRO Series Laser Cutting Machine is a high-performance, heavy-duty laser cutting machine engineered for high-power applications. This model features a hydraulic lifting exchange workbench that allows for rapid positioning and installation, significantly enhancing operational flexibility and efficiency. It is especially well-suited for industries such as sheet metal processing and machinery manufacturing. The machine is compliant with Directive 2006/42/EC (CE Standard), providing comprehensive protection for laser operation safety.
Product Information
Model:
BOLT VII PRO 3015 – 13030
Table Travel(mm):
3100 × 1600 – 13050 × 3020
Accuracy(mm):
0.06
Mechanical Repeatability (mm):
0.02
Maximum Speed (m/min):
Two hundred
Maximum Acceleration (G):
2.8
Laser Power Option (kW):
6 – 60
Product Details
Characteristics
Based on size, it supports power ranging from 6kW to 60kW, with a travel speed of up to 200m/min and acceleration of up to 2.8G for high efficiency.
Features a capacitive sensor and automatic tracking system, enabling the cutting head to float over the workpiece. Integrated auto-focusing adapts to various plate thicknesses.
Zoned dust removal and a fully sealed design provide high dust collection efficiency and a clean, safe workspace.
Includes a Smart Manager system with a built-in process database. Supports real-time adjustment, corner control, and breakpoint resume to increase material utilization and productivity.
The machine complies with Directive 2006/42/EC (CE Standard).
Deliverable in standard HQ containers for select models.
Optional Configurations
Automatic Nozzle Exchanger
Automatic Beam Centering
Gas Mixer
Blue Eye
Compatible with Automation
Fly Cutting
UL Standards Compliance
Bevel Module
Technical Parameters
| Model | BOLT VII PRO 3015 – 13030 |
| Table Travel (mm) | 3100 × 1600 – 13050 × 3020 |
| Accuracy (mm) | 0.06 |
| Mechanical Repeatability (mm) | 0.02 |
| Maximum Speed (m/min) | 200 |
| Maximum Acceleration (G) | 2.8 |
| Laser Power Option (kW) | 6 – 60 |
Applications
