Standard Welding Platform with Shield

Penta Laser Standard Welding Platform series products are the preferred choice for welding equipment in the precision manufacturing sector, thanks to industry-customized process solutions, intelligent and efficient linkage control, a convenient and fast delivery system, and precise, controllable parameter management—safeguarding the welding production of clients across industries.

Product Information

Model:

IPW 0503S

Equipment Dimensions (mm):

1200 × 1000 × 1800

Air Supply (MPa):

0.5 ~ 0.7

Power Supply (Hz):

380VAC 50

Laser Type:

FFRC - H, FFRC - SM, FFRQ, FFSC

Laser Power (W):

300 ~ 6000

Welding Head Type:

Collimator Head, Swing Head, 2D Galvanometer, 3D Galvanometer

Welding Dimensions (mm):

500 × 300 × 200

Inquiry

Product Details

Characteristics

Suitable for small-scale welding in precision sheet metal, medical, sensor, automotive, and new energy industries.

Adapts laser setups and tooling to specific industries for diverse welding applications.

Standard welding software supports 3-axis and 4-axis coordinated welding.

Standard welding platform ensures fast delivery and on-site commissioning.

Collects key process parameters such as welding power and speed.

Optional Configurations

Welding Rotary Positioner

Automatic Visual Positioning Calibration

Technical Parameters

Model	IPW 0503S
Equipment Dimensions(mm)	1200 × 1000 × 1800
Air Supply(MPa)	0.5 ~ 0.7
Power Supply(Hz)	380VAC 50
Laser Type	FFRC - H,FFRC - SM,FFRQ,FFSC
Laser Power(W)	300 ~ 6000
Welding Head Type	Collimator Head,Swing Head,2D Galvo,3D Galvo
Welding Dimensions(mm)	500 × 300 × 200

Applications
